【樣冊P85】SD型 橡膠減振墊 SD rubber damping pad

上海淞江減震器集團有限公司官方網站電子樣冊欄目為您介紹：【樣冊P85】SD型 橡膠減振墊 SD rubber damping pad信息，淞江集團為您提供泵房減振降噪解決方案，為了提高減振效果可將減振墊適合二層、三層、四層串聯使用。適用于水泵、風機、壓縮機、冷水機組、柴油機組等機械設備消除減振。

產品重要特點與用途? Characteristics and use of products
SD型橡膠剪切隔振墊以橡膠為彈性材料經硫化模壓成型，其波浪狀表面可降低隔振墊垂向剛度，隔振墊基本塊尺寸為84x84x20(mm)該系列產品由一種規格尺寸，三種橡膠硬度隔振墊組成，承載范圍從0.2KN~6KN。為提高隔振效果，可多層隔振墊串聯使用，并各層之間以金屬薄板(3mm)隔開，n層串聯隔振墊總剛度為單層的1/n倍，考慮到垂向穩定性，串聯后隔振墊的總高度不應超過隔振墊的寬度，當被隔振體較輕時，可將隔振分割成1/2塊使用，分割后隔振墊承載能力及剛度也為原來的1/2倍，分割后的隔振墊也可再串聯使用。

The SD rubber? shock absorber is manufactured by vulcanization using oil resistant rubber and stretch materials:whost surface can reduce the vertical rigidity.The basic dinension of the shock absorber cushion is 84x84x20(mm).The load range covers from 0.2~6KN．It needs no isolation walls.To improve shock absorption effect, multi-layer.isolation cushion should be used.Sepa-rate, layers can be separated by metal sheet(3mm). The total rigidity of nlayers of cushion are 1/n that of a single layer.When the isolated object is relatively lighter, you can cut itinto 2 pieces.The rigidity is 1/2 that of the original one. The separated isolating cushion can also be used inseries.

SD型橡膠減振墊采用優質橡膠為材料，有圓形凹陷鏤空、剪切瓦楞形。一般以剪切形受力為主，具有固有頻率低、結構簡單、使用方便。為了提高減振效果可將減振墊適合二層、三層、四層串聯使用。適用于水泵、風機、壓縮機、冷水機組、柴油機組等機械設備消除減振。

SD type rubber shock pad is made of high quality rubber as the material, there is a circular depression, corrugated hollow shear. In general, shear force, has low natural frequency, simple structure, easy to use. In order toimprove the damping effect of the damping pad for two layer, three layer, four layer series. Suitable for waterpump, fan, compressor, chiller, diesel and other mechanical equipment of negative damping.
產品尺寸：170mm*170mm*20mm???? 150mm*150mm*20mm???? 120mm*120mm*20mm???? 50mm*50mm*20mm
Product size
